Wooden Gazebo 686 - Apex Roof, Felt Tiles
1
2
3
4
5
6
7
8
9
10
Play Video
Pictures 1, 2, 3, 4 and 5 show the 10'x13' (3.0x4.0m) gazebo. Pictures 6, 7 and 8 show the 13'x18' (4.0x5.5m) gazebo. All pictures show the gazebo treated with optional factory finish treatment. Picture 9 shows the optional paint colours available.

Summary:

These quality wooden carport gazebos are available in sizes approximately 10'x13' and 13'x18' (3x4m and 4x5.5m). Quality features include substantial 4"x4" posts (100x100mm) with angled braces. The apex roof features heavy duty timber supports with 19mm thick tongued and grooved boards. The price includes decorative felt tiles in a choice of colours. Factory finished preservative treatment is available as an optional extra. These luxury gazebos are ideal for use as a hot tub cover, smoking shelter or carport. Instructions are supplied for easy self assembly. We offer fitting as a low cost option in many areas.

Back to the Top
  • All timber used in the construction of this gazebo originates from sustainable forests
  • Suitable as a smoking shelter or hot tub cover
  • Possible use as a carport
  • Strong support posts approximately 100mm x 100mm (finished size after machining)
  • 4 posts included with angled braces (3x4m)
  • 6 posts included with angled braces (4x5.5m)
  • The roof is supplied unassembled with the rafters and roof boards cut to size
  • 19mm thick tongued and grooved roof boards (finished size after machining)
  • Weatherproof L-shaped double fascia boards to front and rear
  • Decorative mineral felt tiles included in a choice of colours
  • Eaves height approximately 7'9" (2.36m)
  • Ridge height approximately 9'5" (2.86m) on 9'10" (3.0m) deep gazebos
  • Ridge height approximately 10'3" (3.13m) on 13'1" (4.0m) deep gazebos
  • External roof overhang approximately 12" to all sides (300mm)
  • This building is easy to deliver if access is restricted - all sections will pass through a normal single door

NORDIC SPRUCE: This building is manufactured from 100% Nordic Spruce, the best quality timber used in log cabin construction. Nordic Spruce is grown primarily in the well managed forests of Scandinavia, Siberia and the coldest parts of Northern Europe. The cold climate ensures slow growth. The growth rings are much closer together than trees grown in warmer climates. As a result the timber is heavy and durable with a dense grain pattern. These forests are expertly managed on a sustainable basis so Nordic Spruce is an enviromentally friendly choice.

DECORATIVE FELT TILES: Mineral coated bitumen felt tiles are an attractive and durable roofing material which is far more hardwearing than standard roofing felt. Traditionally used for small buildings only in the UK, felt tiles are used much more in Scandinavia and North America where they are used widely in general housebuilding. The sophisticated design features a strip of almost dry bitumen adhesive. Over time each tile sticks to the tile below for improved waterproofing and windproofing. All fixings are covered by the next row of felt tiles, partly to ensure a neat appearance with concealed fixings but mainly to protect the fixing holes from any possible moisture. Mineral felt tiles are made using asphalt with a bitumen binder and an external covering of durable and attractive natural stone chips. Mineral felt tiles are often described as felt shingles because the design resembles traditional cedar shingles.

SIZES - LENGTH AND WIDTH: Sizes are sometimes rounded to the nearest nominal size for ease of reading but the correct external wall sizes are listed alongside the price. The first dimension listed is the depth and the second dimension is the width. All sizes quoted are the external gazebo sizes and do not include any roof overhang, unless stated otherwise. Many other suppliers quote the overall roof size which is much larger. All sizes are approximate.
